These pumps are suitable for all types of coolant having viscosity upto 150 centristrokes at 60°C temperature.
Coolant pump is designed for continuous operation on 415 Volts, 50 Hz, 3 Phase supply and suitable for direct-on-line starting
Coolant Pump is a combined unit of squirrel cage stator-rotor and uni-built immersion type centrifugal pump. These are used for the supply of coolant on the working surface of machine tools. Coolant pumps are fitted on the chamber containing the coolant and the pump portion is immersed in the liquid. Hence no priming is required
SM1 is recommended for centre lathe, drilling, milling and light duty machine tools
SM2 is recommended for turret lathe, grinding and heavy duty machine tools
Coolant pump for other voltages, single or dual up to 600 Volts and 60 Hz
ON-OFF rotary switch in place of terminal box
Pump for 240 volts single phase supply
Dust and Splash-proof (IP 54) terminal box
Triple Protection to prevent coolant ingress into the winding
Position of conduit entry can be adjusted through every go0 by rotating the terminal box
Relative Position of terminal box to coolant out-let can be adjusted through every go0 by rotating the body
The mounting of the cover on to the terminal box is independent of mounting of the terminal box on to the motor
Earthing bolts provided
Sturdier shaft to prevent bending at pump end
Aluminium impeller offers high resistance to abrasion
Large passages prevent clogging of coolant
Dynamically balanced rotor ensures silent and vibration free running
Stator winding impregnated under vacuum to work in tropical climate
Class ' F' Insulation
High discharge with low power consumption
NOTE:
Due to continuous Research & Development based on Market Feedback models, shapes and dimensions are subject to changes without notice.
Kindly confirm the dimensions at the time of order.
